Even in an age of moving maps, reading a VFR sectional chart is a fundamental pilot skill. Sectionals pack an enormous amount of information into colour, symbols and lines — airspace, terrain, obstacles, airports and navigation aids. Here is how pilots make sense of it.
Why VFR charts still matter
Digital apps are excellent, but the sectional remains the reference. Understanding the underlying chart makes you a safer, more aware pilot — and a working knowledge of symbols and airspace is tested on every checkride.
Decoding chart symbols
Sectionals use standardised symbols for airports (towered shown in blue, non-towered in magenta), navigation aids, obstacles with their heights, and landmarks. The chart legend is your key — experienced pilots know the common symbols by heart but still reference the legend for the unusual ones.
Airspace classifications
US airspace is divided into classes:
- Class A — high altitude, IFR only.
- Class B — busiest airports; clearance required (solid blue lines).
- Class C — moderately busy; two-way comms required (solid magenta).
- Class D — towered fields (dashed blue).
- Class E — controlled airspace (magenta/blue shading).
- Class G — uncontrolled airspace.
Reading where these begin and end — laterally and vertically — is central to VFR flying.
Special-use airspace
Charts also show special-use airspace such as restricted, prohibited, military operations and warning areas. Knowing what each means — and when it is active — keeps you clear of trouble.
Reading the terrain
Colour shading and contour lines show elevation, while spot heights and obstacle symbols flag the highest points. Reading terrain helps with safe altitudes and emergency planning.
Digital alternatives
Apps like ForeFlight and Garmin Pilot display the same sectional data with GPS overlay — powerful, but most useful when you already understand the chart underneath. Build the foundation first.
Frequently asked questions
What is a VFR sectional chart?
It is a visual navigation chart showing airspace, terrain, obstacles, airports and navigation aids, used by pilots flying under Visual Flight Rules.
What do the magenta and blue airport symbols mean?
Blue airport symbols indicate towered airports; magenta indicates non-towered. Airspace boundaries also use blue and magenta lines for different classes.
Do pilots still use paper sectionals?
Many use digital apps, but understanding the sectional remains essential — the same data underlies the apps, and chart reading is a core, tested skill.
